-Meritan is your reliable China quality TCB-SA Temperature Controller for Micro TECs manufacturer. For industrial automation systems requiring extreme thermal stability, the TCB-SA Temperature Controller Board for Micro TECs provides a high-precision interface with an accuracy of 0.01°C. By leveraging integrated circuits specifically designed for high-end thermoelectric systems, X-Meritan delivers reliable, China-manufactured solutions to global partners in the laser and semiconductor industries.
The TCB-SA Temperature Controller for Micro TECs made in China by X-Meritan is a specialized control module engineered for small-scale thermally conductive elements. This TCB-SA Micro TECs Thermoelectric Cooler Temperature Controller utilizes a comprehensive PID control algorithm to ensure that delicate electronic components remain within their optimal operating windows. As a professional manufacturer with a dedicated China-based factory, X-Meritan ensures that every controller provides continuous power delivery to the TEC, eliminating the fluctuations associated with intermittent power cycles and providing a stable environment for sensitive instrumentation.
| Parameter | Technical Requirement / Value |
| Board Supply Voltage (DC) | 5V |
| Board Supply Current | Depends on the specific TEC load |
| Output Efficiency | Greater than 90% |
| TEC Voltage | 4.5V (Default) |
| TEC Current | 3.0A (Maximum) |
| Temperature Sensor Type | 10K NTC (Default B value: 3950) |
| Control Accuracy | 0.01 degree C |
| Set Temperature Accuracy | 0.01 degree C |
| Measurement Range | -30 to 147 degrees C |
| Control Temperature Range | -20 to 100 degrees C |
| Factory Default Set Temp | 25 degrees C (or user-specified) |
| Dimensions (L x W) | 60mm x 42mm |
| Board Height | 23mm (Total) |
| Component Height | 18.5mm (Above board) |
| Board Thickness | 1.5mm |
| Pin Clearance | Maximum 3mm (Below board) |
Specialized Control Architecture
Built with a high-end integrated circuit (IC) dedicated to TEC management, the board achieves a superior temperature control accuracy of 0.01°C.
Continuous Power Supply
Unlike standard pulse-width modulation, the TCB-SA supplies continuous power to the cooling element, ensuring a smooth thermal gradient and stable temperature throughout the entire control cycle.
Refined PID Algorithm
The onboard PID logic is fully optimized for micro-scale thermal masses, allowing for rapid response times and minimal overshoot during setpoint transitions.
Broad Sensor Compatibility
The controller is fully compatible with 10kΩ NTC temperature sensors, the industry standard for high-precision thermal monitoring in micro-electronics.
Proven Industrial Reliability
The performance of the TCB-SA Temperature Controller for Micro TECs has been verified through long-term, large-scale applications in the laser field, where thermal requirements are exceptionally stringent.
Optimized for Micro Component
Specifically designed for small-form-factor TECs, the board's electrical characteristics are tuned to prevent overstressing delicate semiconductor cooling junctions.
Laser Diode Stabilization: Ensures consistent wavelength output in high-end laser systems by maintaining ultra-stable temperatures for the diode housing.
High-Precision Optical Sensors: The TCB-SA Temperature Controller for Micro TECs reduces thermal noise in sensitive optical detectors by providing a rock-steady cooling environment.
Semiconductor Research: Ideal for laboratory setups requiring micro-scale thermal control where space is limited and 0.01°C precision is mandatory.
