X-Meritan is a leading China quality Direct to Liquid Thermoelectric Coolers Assemblies supplier. We specialize in the high-precision manufacturing of Direct to Liquid Peltier Coolers Assemblies, providing advanced solid-state thermal management for complex industrial systems. By leveraging our certified factory's capabilities, X-Meritan delivers Direct to Liquid Peltier Cold Plates that eliminate the need for traditional refrigerants, ensuring sustainable and efficient performance for global customers.
These high quality Direct to Liquid Thermoelectric Coolers Assemblies from X-Meritan utilize a low-voltage DC power supply to actively transfer heat between integrated thermoelectric modules and a liquid medium. As a versatile thermal solution, these Direct to Liquid Thermoelectric Coolers Heat Exchangers can seamlessly switch between cooling and heating modes simply by reversing the current polarity. Each unit is constructed with high-grade n-type and p-type semiconductor materials mounted between durable ceramic substrates, providing both electrical insulation and structural integrity for precise temperature control applications.
|
Model |
Cooling Capacity (W) |
Temperature Range (°C) |
Flow Rate (L/min) |
Voltage (VDC) |
Port Size |
Dimensions (L×W×H mm) |
|
DTC-050 |
50 |
5 ~ 40 |
0.5 ~ 2 |
24 |
G1/4" |
150×100×80 |
|
DTC-200 |
200 |
0 ~ 50 |
1 ~ 5 |
24 / 48 |
G1/4" |
200×150×100 |
|
DTC-500 |
500 |
-5 ~ 60 |
2 ~ 8 |
48 |
G3/8" |
280×200×120 |
|
DTC-1000 |
1000 |
-10 ~ 80 |
5 ~ 10 |
48 / 72 |
G3/8" |
350×250×150 |
● Dual-Function Thermal Control
These assemblies can be used for both heating and cooling, offering high flexibility for systems that require stabilization across varying ambient temperatures.
● Precise Temperature Regulation
By modulating the DC voltage, the system achieves extreme accuracy in liquid temperature management, far exceeding the capabilities of mechanical thermostats.
● Solid-State Reliability
With no moving parts other than potential secondary fluid pumps, the core cooling mechanism is exceptionally rugged and features a long operational lifespan.
● Versatile Power Modes
In addition to active cooling, the integrated thermoelectric modules can be utilized for power generation when a sufficient temperature differential is applied across the substrates.
● Customizable Configurations
We offer a variety of shapes, substrate materials, and metallization patterns to ensure the assembly fits perfectly within your specific mechanical footprint.
Unlike traditional compressor-based cooling systems, Direct to Liquid Thermoelectric Coolers Assemblies do not require Freon or other chemical refrigerants, making them an environmentally superior choice. While compressors are often bulky and prone to mechanical failure over time, our solid-state assemblies provide a compact, vibration-free solution that operates silently. Furthermore, the ability to reverse heat flow instantaneously via polarity switching allows for a dynamic range of thermal control that traditional phase-change systems cannot replicate without complex secondary valving.
Our Direct to Liquid Thermoelectric Coolers Assemblies now has been widely used.
Laboratory Instrumentation: Used for precise cooling of reagents and samples where vibration from a compressor could interfere with sensitive measurements.
Medical Equipment: Ideal for laser surgery cooling and diagnostic imaging systems that require silent, reliable, and compact thermal management.Semiconductor Processing: Utilized in the thermal regulation of chemical baths and etching fluids where high-precision liquid cooling is mandatory.
1. Seasoned Technical experience Accumulation: We have been deeply engaged in thermoelectric refrigeration technology for many years, amassing significant industry experience and technical expertise.
2. ISO9001 Quality Assurance: Our production and management processes strictly follow the ISO9001 quality management system to ensure every assembly is stable and reliable.
